THIS UNIT IS EQUIPPED WITH 10000# AXLES, DUAL JACKS, 12″/19# PIERCED I-BEAM FRAME, WINCH PLATE IN NECK, TORQUE TUBE, AND FULL WIDTH RAMPS.
With a GVWR of 22,500 lbs., the LKX Low-Pro Gooseneck Flatbed is a purpose-built trailer for contractors, ranchers, and fleet owners. Featuring a 12″ I-beam frame, 5′ dovetail with MAXX-D out ramps, and standard Dexter 10K axles, the LKX delivers reliable performance in our most requested flatbed configurations.
A FLATBED YOU CAN COUNT ON. BUILT FOR WORK. PRICED TO MOVE.
The MAXX-D LKX Low-Pro Tandem Dual Flatbed Trailer is built for one thing: getting the job done. Designed around our most-requested, most-produced configurations, the LKX gives you everything you need-and nothing you don’t. It’s a serious flatbed for haulers who want MAXX-D strength in a simplified, work-ready platform.
Available in deck lengths from 25′ to 40′, every LKX comes standard with a 12″ x 19 lb I-beam frame, dual 10K Dexter electric brake axles, 5′ dovetail with MAXX-D out ramps, slipper spring suspension, 2×8 treated wood floor, flushmount LED lighting, and a spare mount, all finished in wet black primer and paint. These are field-proven specs we build week in and week out-no custom confusion, just real-world reliability.
The LKX is ideal for contractors, ranchers, builders, and business owners who need a dependable, no-fluff flatbed that’s built to haul and priced to move. With consistent configurations, fast turnaround, and trusted MAXX-D quality, it’s the trailer your crew can count on from the first job to the last.
LKX10225 – AS EQUIPPED
25′ X 102″ – Low-Pro Tandem Dual Flatbed
G17: 25,000 LB GVWR
C17: 2 5/16″ 30K ROUND GN COUPLER
J18: 2-10K DROP-LEG JACKS
N21: STANDARD HEIGHT I-BEAM NECK W/ FR T-BOX,
WINCH PLT, & SP MT
F45: 12″ X 19LB I-BEAM FRAME WITH TORQUE TUBE
X19: 3″ I-BEAM ON 16″ CENTERS
R06: 6″ CHANNEL OUTER FRAME
D36: 5′ DOVETAIL/MAXXD-OUT RAMPS
A33: 2-10K ELECTRIC BRAKE AXLES
S02: SLIPPER SPRING SUSPENSION
T26: DUALS (8) ST235/80R16 E TIRES
E04: 2X8 TREATED WOOD FLOOR
L03: FLUSHMOUNT LED’S / STANDARD SEALED WIRING
HARNESS
O02: MAXXD GRAY METALLIC & PRIMER
Y65: SPARE MOUNT
